15000 GVWR Deluxe Diamond Floor Skid Steer Trailer - 20 ft.

Our 15000 GVWR Deluxe Diamond Floor Skid Steer Trailer is built with a 6 in. x 4 in. x 3/8 in. angle iron frame, 6" channel full length wrap around tongue, a 12,000 lb. drop foot jack and a heavy duty cast iron adjustable coupler. 7,000 lb. four wheel brake axles with heavy duty slipper spring suspension and 235/80 R16 load range E tires make up the running gear. A tool box with a lockable lid, stake pockets with rub rail, and heavy gauge diamond plate fenders are all included. We beef up the ramps with 4 in. channel ramp runners. Spring assist is included. A sealed modular wiring harness and lifetime LED lights ensure trouble free wiring. Contact our customer service team today to find out how easy it is to have a 15000 GVWR Deluxe Diamond Floor Skid Steer Trailer delivered direct to your location.

3 Available Lengths

$8,090.00

*Cash Price Listed. 3% processing fee added for payments not made by cash, wire, or cashier’s check.

See Lengths & Prices

866.455.7444

Download Brochure Kaufman Trailer Parts

G.V.W.R.:	15,000 lb.
Deck Height:	20 in.
Electrical:	Sealed modular wiring harness with LED lights
Deck Width:	82 in. Between fenders
Frame:	4x6x3/8 angle frame, with 3 in channel crossmembers with support strips on 16 in. centers
Fenders:	Diamond plate fenders
Tongue:	6 in. Channel wrap around
Brakes:	All wheel electric brakes
Tires:	235/80 R16 LRE (3,520 lb)
Wheels:	Silver or white mod (Based on stock)
Floors:	Full diamond plate
Jack:	12,000 lb. Drop foot jack
Coupler:	2-5/16 in. Adjustable ball coupler
Axles:	2-7,000 lb. e-z lube axles
Safety Chains:	Heavy duty safety chains
Suspension:	Slipper springs
Ramps:	60 in. x 20 in. heavy duty flip up ramps - 4 in. channel ramp runners - with spring assist
Toolbox:	Chain box with lockable lid standard
Tie Downs:	Stake pockets and Rubrail
Finish:	Primed, 2 coats of automotive grade enamel, pin striped
Deck Length:	20 ft.

Option	Price	Image
Spare tire and rim	$230.00
20,000 GVWR Heavy Duty Package - Includes 3/7,000 lb. axles, required flat adjustable nose plate with pintle ring coupler, standard 6 in. channel frame with 5 in. channel frame doubler, 16 in. on center crossmembers, and heavy duty spring assist ramps (*Premium tire upgrade for this option requires special quote*)	$1,800.00
Load Range G (14 ply rating) all-steel radials	$500.00
Adjustable 2-5/16 in. ball and pintle ring	$60.00
Load Range G (14 ply rating) all-steel radial - spare tire	$300.00
No ramps (Straight deck) *Special deposit required	$-50.00
6K Winch	$950.00
Fork holders (requires measurement information)	$200.00
9K Winch	$1,250.00
5 ft. Heavy duty spring assist split gate (Capacity 13,000 lb. piece of equipment)	$600.00

Product Number	Length	Price	Additional Info
FSD-7K-16D	16 ft.	$8,070.00	Frame: 4x6x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in.
FSD-7K-18D	18 ft.	$8,080.00	Frame: 4x6x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in.
FSD-7K-20D	20 ft.	$8,090.00	Frame: 4x6x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in.
